Description
C27450 Lead Free Brass to not only aid in lead free compliance, but to optimize manufacturing efficiencies through productivity & complete recyclability.
Application
Technincal Specification
| CATEGORY | ASTM | BS | EN | JIS | DIN | ISO | IS |
| Lead Free Brass | C27450 | CZ121 | CuZn37 |
| Equivalent Specifications : | ||
| Specifications | Designation | |
| ISO | CuZn37 | |
| Europen | CW508L | |
| BS | ||
| JIS | C27450 | |
| Russian | ||
Typical Application
| Typical Applications : | ||
| C27450 DZR Lead Free Brass |
|
|
Advantages
| Advantages : | ||
| C27450 DZR Lead Free Brass |
|
|
Chemical Composition
| Chemical Composition: | |||||
| Cu | Pb | Fe | Zn | Others | |
| Min/Max | 60-65 | <0.25 (max) | 0.35 | Rem | <0.5 |
| Nominals | 63.00 | 37.00 | |||
Mechanical Properties
| Mechanical Properties: | ||||
| Rod H02 | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation (%) | Hardness (Rb) |
| 58 | 40 | 30% | 55-75 | |
Fabrication Properties
| Fabrication Properties : | ||
| Soldering | Excellent | |
| Brazing | Excellent | |
| Cold working | Excellent | |
| Plating | Excellent | |
| Forgability | 95 | |
| Machinability | 70 | |
Sizes Available
| Sizes Available : | ||
| Soldering | Excellent | |
| WIRE | 1mm TO 8 mm | |
| HOLLOW RODS | Min Bore Size 20 mm and Max OD 100 mm | |
| ROUND RODS | 6mm To 130 mm | |
| HEX | 5mm To 60mm | |
| SQUARE | 4mm To 60mm | |
| FLAT | 5mm Min Thickness and max Width 120mm | |
| PROFILES / SECTIONS | AS per Customer Drawing | |
| BILLETS | Up to 200mm | |
| INGOTS | AS per Specification | |
